Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
type-W219-typical-landing-doorverified · printed
applicability
TYPICAL FOR ALL OPENINGS TO ELEVATOR #3; FOR BASEMENT OPENINGS TO ELEVATORS #1 & #2; & FOR ALL OPENINGS ABOVE FIRST FLOOR TO ELEVATORS #1 & #2 UNLESS OTHERWISE SHOWN.Printed relational scope only; floor IDs are not expanded from this sheet. landing-door type only Authoring eligibility: eligible-only-with-the-printed-elevator-and-floor-scope.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: TYPICAL FOR ALL OPENINGS TO ELEVATOR #3; FOR BASEMENT OPENINGS TO ELEVATORS #1 & #2; & FOR ALL OPENINGS ABOVE FIRST FLOOR TO ELEVATORS #1 & #2 UNLESS OTHERWISE SHOWN.
type-W219-typical-landing-doorverified · observed
leaf_count
Two door leaves drawn in the typical elevation2 count
per W219-landing-door-applicability type-W219-typical-landing-door Authoring eligibility: eligible-local-type-composition.
type-W219-typical-landing-doorverified · observed
recessed_square_panel_count_per_leaf
Five square recessed/relief panels drawn vertically on each leaf5 count
per W219-landing-door-applicability each of the two landing-door leaves Authoring eligibility: eligible-local-type-composition.
type-W219-typical-landing-doorverified · printed
door_material
METAL ELEVATOR DOORSper W219-landing-door-applicability landing-door leaves Authoring eligibility: eligible-material-only.
type-W219-typical-landing-doorverified · printed
trim_material
METAL TRIMper W219-landing-door-applicability typical landing-door surround Authoring eligibility: eligible-material-only.
type-W219-typical-landing-doorverified · printed
plinth_material
MARBLE PLINTHper W219-landing-door-applicability typical landing-door surround Authoring eligibility: eligible-material-only.
type-W219-metal-cab-planverified · printed
applicability
TYPICAL FOR ELEVATORS 1 & 2 & 3cab plan only Authoring eligibility: eligible-for-plan-properties-only.
type-W219-metal-cab-planverified · printed
outer_horizontal_plan_witness
6'-8"6.666667 ft
The extension lines bound the outer plan envelope. The sheet does not name this value platform width, car clear width, or hoistway width. outer horizontal dimension line over the metal-cab plan Authoring eligibility: eligible-as-local-witness-only.
type-W219-metal-cab-planverified · printed
inner_horizontal_plan_witness
6'-4"6.333333 ft
The value is retained as a distinct inner plan witness. It is not renamed cab clear width or platform width. inner horizontal dimension line over the metal-cab plan Authoring eligibility: eligible-as-local-witness-only.
type-W219-metal-cab-planverified · printed
left outer-to-inner horizontal side segment
2"2 in
left and right horizontal chain segments between the 6'-8" and 6'-4" witnesses. Authoring eligibility: eligible-as-local-witness-only. The segment is not a wall or platform thickness.
type-W219-metal-cab-planverified · printed
right outer-to-inner horizontal side segment
2"2 in
left and right horizontal chain segments between the 6'-8" and 6'-4" witnesses. Authoring eligibility: eligible-as-local-witness-only. The segment is not a wall or platform thickness.
type-W219-metal-cab-planverified · printed
outer_vertical_plan_witness
4'-10 3/4"4.895833 ft
The value is not promoted to platform depth or inside-clear cab depth. right-side vertical dimension line at the cab body, excluding the separately chained front projection Authoring eligibility: eligible-as-local-witness-only.
type-W219-metal-cab-planverified · printed
floor_finish
[thickness unreadable] RUBBER TILE FLOORcab floor plan Authoring eligibility: eligible-material-only. Missing: Tile thickness.
type-W219-metal-cab-planverified · printed
ceiling_emergency_exit_presence
EMERGENCY EXIT1 count
half ceiling plan Authoring eligibility: eligible-presence-only. Missing: Emergency-exit clear dimensions. Missing: Hinge, latch, and access direction.
type-W219-metal-cab-planverified · printed
cab_sill_material
BRONZE SILLcab entrance sill Authoring eligibility: eligible-material-only. Missing: Sill width, depth, profile, groove, and attachment.
type-W219-metal-cab-planverified · printed
cab_door_material
HOLLOW METAL CAB DOORScab doors in the metal-cab plan Authoring eligibility: eligible-material-only.
type-W219-cab-E-elevation-assemblyverified · printed
view_relationship
HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REARCab E elevation assembly Authoring eligibility: eligible-local-composition-only.
type-W219-cab-E-elevation-assemblyverified · printed
head_grille_material
CAST BRONZE GRILLEcab elevation head/frieze grille Authoring eligibility: eligible-material-and-location-only.
type-W219-cab-E-elevation-assemblyverified · printed
interior_railing_material
[size unreadable] BRONZE RAILINGThis is an interior cab railing, not a hoistway guide rail. cab interior railing Authoring eligibility: eligible-material-only. Missing: Rail section size. Missing: Railing height. Missing: Exact return geometry.
type-W219-cab-E-elevation-assemblyverified · printed
railing_bracket_material
CAST BRONZE BRACKETScab interior railing brackets Authoring eligibility: eligible-material-only.
type-W219-cab-E-elevation-assemblyverified · printed
front_door_material
HOLLOW METAL DOORfront half-elevation of Cab E Authoring eligibility: eligible-material-only.
type-W219-metal-cab-planunreviewed · observed
platform_width
UnresolvedNumeric value unresolved
No dimension on the reviewed region is printed as PLATFORM width; the 6'-8" and 6'-4" plan witnesses are not relabeled.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-metal-cab-planunreviewed · observed
platform_depth
UnresolvedNumeric value unresolved
No dimension is printed as PLATFORM depth; 4'-10 3/4" remains an outer cab-plan witness.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-metal-cab-planunreviewed · observed
inside_clear_width
UnresolvedNumeric value unresolved
The 6'-4" dimension is not labeled CLEAR and is not promoted to a clear dimension.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-metal-cab-planunreviewed · observed
inside_clear_depth
UnresolvedNumeric value unresolved
No printed clear-depth label or securely classified inner endpoint pair was found.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-cab-E-elevation-assemblyunreviewed · observed
cab_height
UnresolvedNumeric value unresolved
Small vertical dimension text could not be read securely enough for transcription.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REAR; CAST BRONZE GRILLE; BRONZE RAILING; CAST BRONZE BRACKETS; HOLLOW METAL DOOR
type-W219-typical-landing-doorunreviewed · observed
landing_door_clear_width
UnresolvedNumeric value unresolved
No securely readable width with classified operating-clear endpoints was established.
type-W219-typical-landing-doorunreviewed · observed
landing_door_clear_height
UnresolvedNumeric value unresolved
The photographed dimension text/endpoints do not securely establish an operating-clear height.
type-W219-hoistway-equipment-unresolvedunreviewed · observed
car_and_counterweight_guide_rails
UnresolvedThe printed BRONZE RAILING is a cab-interior handrail/railing, not a hoistway guide rail. No guide-rail section, size, spacing, bracket, or placement was printed in the reviewed W219 elevator regions.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REAR; CAST BRONZE GRILLE; BRONZE RAILING; CAST BRONZE BRACKETS; HOLLOW METAL DOOR
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-typical-landing-doorunreviewed · observed
landing_sill_profile_and_dimensions
UnresolvedThe cab plan labels a BRONZE SILL, but that note is not transferred to the landing-door sill and no secure landing-sill profile was extracted.
type-W219-typical-landing-doorunreviewed · observed
landing_door_head_construction_and_dimensions
UnresolvedNo securely readable printed head assembly specification or exact dimension was established.
type-W219-hoistway-equipment-unresolvedunreviewed · observed
pit_depth_and_equipment
UnresolvedW219's reviewed elevator regions contain door/cab architectural details, not a pit section.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REAR; CAST BRONZE GRILLE; BRONZE RAILING; CAST BRONZE BRACKETS; HOLLOW METAL DOOR
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-hoistway-equipment-unresolvedunreviewed · observed
overhead_height_and_clearances
UnresolvedNo overhead or top-clearance section is printed in the reviewed W219 elevator regions.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REAR; CAST BRONZE GRILLE; BRONZE RAILING; CAST BRONZE BRACKETS; HOLLOW METAL DOOR
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-hoistway-equipment-unresolvedunreviewed · observed
machine_and_drive_equipment
UnresolvedNo machine, motor, sheave, governor, rope, controller, or power specification is printed in the reviewed W219 elevator regions.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: HALF REAR; HALF FRONT; FRONT & REAR ELEVATIONS OF ELEVATOR CABS; SIDE ELEVATIONS SIMILAR TO REAR; CAST BRONZE GRILLE; BRONZE RAILING; CAST BRONZE BRACKETS; HOLLOW METAL DOOR
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
type-W219-metal-cab-planunreviewed · observed
world_placement
UnresolvedNo W219-to-W3 registration was attempted, and no photographed pixel distance was used as a physical measurement.
IMG_1307 · sheet-W219 · Locate on drawing ↗Drawing notation: PLAN OF METAL ELEVATOR CABS; TYPICAL FOR ELEVATORS 1 & 2 & 3; 6'-8"; 6'-4"; 2"; 2"; 4'-10 3/4"; RUBBER TILE FLOOR; EMERGENCY EXIT; BRONZE SILL; HOLLOW METAL CAB DOORS
lobbyprofiles1013q-w219-ceiling-grille-typeverified · printed
grille-material
CAST PLASTER GRILLEPrinted source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
IMG_1307 · W-219 · Locate on drawing ↗Drawing notation: CAST PLASTER GRILLE
Printed source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
lobbyprofiles1013q-w219-ceiling-grille-typeverified · printed
screen-relationship
WALL SCREEN BEHINDPrinted source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
IMG_1307 · W-219 · Locate on drawing ↗Drawing notation: WALL SCREEN BEHIND
Printed source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
lobbyprofiles1013q-w219-cornice-model47-typeverified · printed
model-mark
MODEL NO. 4747 model-number
Printed source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
IMG_1307 · W-219 · Locate on drawing ↗Drawing notation: MODEL NO. 47
Printed source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
lobbyprofiles1013q-w219-cornice-model47-typeverified · observed
complete-drawn-rosettes-in-cropped-view
Three complete rosettes visible in the bounded cornice view3 drawn-detail-count
Three complete drawn motifs in this bounded source view, not installed quantity or full-run component count.
IMG_1307 · W-219 · Locate on drawing ↗Drawing notation: Three complete rosettes visible in the bounded cornice view
Three complete drawn motifs in this bounded source view, not installed quantity or full-run component count.
lobbyprofiles1013q-w219-cornice-model47-typeverified · printed
drawing-scale
1½″ SCALE DETAIL OF CORNICEPrinted source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
IMG_1307 · W-219 · Locate on drawing ↗Drawing notation: 1½″ SCALE DETAIL OF CORNICE
Printed source-local original photographic layer only. Endpoints remain those of the drawn witness; no operating-clear size, accepted world transform, installed count, revision equivalence or closed profile inferred.
