Every dimension belongs to an object and a drawing. Original room numbers, object marks, printed values and source regions stay together—even when the answer is unresolved.
464 of 464 photographs have extraction records, containing 27,517 properties. Initial image review is not exhaustive extraction: 0 photographs have passed the full-region check. 66 numbered sheets are reconciled. Modeling and architectural registration are separate work; these counts do not establish a complete building.
Download the structured register (JSON)Original sheet identity has not yet been reconciled.
Extraction: Reviewed · extraction partial. Partial timed visual review: Partial first-pass visual review of public/archive/drawings/complete-upright/IMG_1297.webp using <=1000px quality65 JPEG locator after OCR/catalogue. Regions refer to the unchanged orientation access image; actual required reading rotation recorded. Fine notes remain unresolved when locator resolution insufficient. Partial timed visual review: Additive targeted crop follow-up; source access derivative 1650x2200, rotated 180 degrees before crop. Partial; source regions mapped back to original access-image coordinates. Original printed specifications only; no separate revision was identified in inspected crops. Partial timed visual review: Additive bounded follow-up after queue, OCR and prior packages; prior verified readings reused without duplication. No full-sheet completion or model acceptance. Partial timed visual review: Additive detailed review of selected regions following OCR and prior packages. Type-level evidence only; no installed position or quantity established. Other fine regions remain partial. Partial timed visual review: undefined Partial timed visual review: undefined Partial timed visual review: undefined Partial timed visual review: undefined Partial timed visual review: Depicted type/component, shop order or source-local assembly only. Components and grille order quantities do not create installed fixtures or establish electrical outlet-to-type assignments. Partial timed visual review: undefined Partial timed visual review: Text-only reconciliation of prior verified packages and OCR. No new measurement, region-completion claim or physical instance created. Partial timed visual review: undefined Partial timed visual review: undefined
Loading the selected drawing…
Scroll or pinch to inspect this drawing. Archival drawing photograph · Oregon Historical Society research collections.
Open source image separately ↗Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
24 in
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: 425 24" BOWL
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
30 in
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: 426 30"
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
34 in
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: 427 34"
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: NO SCALE
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: FINISH OF FIXTURE TO BE OLD IVORY UNLESS OTHERWISE SPECIFIED
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Earlier locator transcription retained for audit, not accepted wording. Targeted crop in closeout-img1297-fixture_425_427_socket_finish_corrected reads PORCELAIN SOCKET FINISHED TO MATCH FIXTURE. Reconcile by using the close-up reading, not this superseded tentative text.
Drawing notation: PORCELAIN SOCKET UNLESS OTHERWISE SPECIFIED IN FIXTURE
Earlier locator transcription retained for audit, not accepted wording. Targeted crop in closeout-img1297-fixture_425_427_socket_finish_corrected reads PORCELAIN SOCKET FINISHED TO MATCH FIXTURE. Reconcile by using the close-up reading, not this superseded tentative text.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: COMPOSITION WITH FIBER BASE
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: DEEP ETCHED ALABASTER GLASS RAISED ORNAMENTATION
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: DEEP ETCHED ALABASTER GLASS RAISED ORNAMENTATION
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Drawing notation: SIDE ELEVATION OF ONE ARM FIXTURE
Selected visually legible property; type/detail-local scope; no building quantity or room geometry inference.
Numeric value unresolved
OCR locator or small tentative text; withheld numeric value and crop verification required.
Drawing notation: [small screw, vent and chain dimensions require crop]
OCR locator or small tentative text; withheld numeric value and crop verification required.
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Corrects tentative batch12-a socket transcription; earlier record retained as conflicting reading.
Drawing notation: PORCELAIN SOCKET FINISHED TO MATCH FIXTURE
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Corrects tentative batch12-a socket transcription; earlier record retained as conflicting reading.
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: SILVER MIRRORED REFLECTOR
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: CHAIN OR REINFORCED SILK COVERED CORD FINISH TO MATCH FIXTURE
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Numeric value unresolved
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
Drawing notation: FIXTURE LENGTH [no numeric value printed beside leader]
Type-local printed property. Crop courthouse-1297-bowl.jpg, source-access pixel rectangle [50,50,750,850] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
4 screws
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: 4 SCREWS No.10-24
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: No.10-24
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
0.125 in
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: REINFORCING RING 1/8" THICK
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: LIKE FIXTURE #558 MAKE FILLER TO SUIT GLASSWARE
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
12 vents
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: 12 [diameter fraction unresolved] VENTS
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Numeric value unresolved
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
Drawing notation: 12-½? VENTS [fraction unresolved]
Type-local printed property. Crop courthouse-1297-581.jpg, source-access pixel rectangle [50,800,800,700] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: PORCELAIN SOCKET TO BE STANDARD BASE UNLESS OTHERWISE NOTED IN SPECIFICATION
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: CAST, HAND FINISHED
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: POLISHED
Type-local printed property. Crop courthouse-1297-579.jpg, source-access pixel rectangle [800,-200,850,1250] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
2 arms
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: PLAN FOR 2 ARMS
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
3 screws
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: 3 No.8-32 SCREWS
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: No.8-32
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
3 screws
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: 3 SCREWS
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
4 screws
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: 4 SCREWS
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Drawing notation: BY PASS COCK / GAS COCK
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). No installed building quantity inference.
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
Drawing notation: SIMILAR TO GLASSWARE ON FIXTURE ... OR AS APPROVED [right edge cropped]
Type-local printed property. Crop courthouse-1297-arms.jpg, source-access pixel rectangle [150,1550,850,650] mapped to source access coordinates via x=x0+w*(1-u), y=y0+h*(1-v). Unresolved; do not normalize guessed fractions.
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Drawing notation: POLISHED
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Drawing notation: CAST; SPUN
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Drawing notation: SIMILAR TO GLASSWARE ON FIXTURE [right edge cropped] OR AS APPROVED
Selected source-access normalized region; printed/type-local property. Nominal pipe/casing sizes are not measured outside diameters. Assignment labels establish intended type use only. Source access orientation recorded at image level.
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Full printed type reference visible in this exposure; retain approval exception.
Drawing notation: SIMILAR TO GLASSWARE ON FIXTURE #550 OR AS APPROVED
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Full printed type reference visible in this exposure; retain approval exception.
Conflicting readings: detail-lighting-img1297-561-glassware_reference closeout-img1297-fixture_561_glass_reference_unresolved
550 identifier
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Printed mark, not fixture quantity.
Drawing notation: FIXTURE #550
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Printed mark, not fixture quantity.
Calculated from: fabrication1013j-img1297-018-glassware_companion_reference_resolved
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Companion confirms base wording and explicit exception; earlier IMG 1296 size wording remains separately preserved.
Drawing notation: PORCELAIN SOCKET TO BE STANDARD BASE UNLESS OTHERWISE NOTED IN SPECIFICATION
Depicted type/component or shop-order row only; no installed quantity or accepted physical geometry. Companion confirms base wording and explicit exception; earlier IMG 1296 size wording remains separately preserved.
Calculated from: closeout-img1297-fixture_579_socket_specification
Conflicting readings: parallel-img1296-m011
0.25 in
Printed component specification for the indicated type specimen only; no installed quantity, world position or building geometry follows. Same581 vent leader as earlier unresolved fraction. Crop reads¼ inch, not the tentative½ transcription. Existing12-vent quantity is reused without duplication.
Drawing notation: 12 - 1/4" VENTS
Printed component specification for the indicated type specimen only; no installed quantity, world position or building geometry follows. Same581 vent leader as earlier unresolved fraction. Crop reads¼ inch, not the tentative½ transcription. Existing12-vent quantity is reused without duplication.
Calculated from: closeout-img1297-fixture_581_vent_quantity
Conflicting readings: closeout-img1297-fixture_581_vent_diameter_unresolved
Original425–427 pendant detail labels the dimension from canopy upper plane to bowl upper plane with words only. The numeric bowl-size list is separate; source NO SCALE prohibits deriving this gap from image proportions.
Drawing notation: FIXTURE LENGTH
Original425–427 pendant detail labels the dimension from canopy upper plane to bowl upper plane with words only. The numeric bowl-size list is separate; source NO SCALE prohibits deriving this gap from image proportions.
Numeric value unresolved
Full label and endpoint witness independently inspected at native source resolution; no dimension number appears. This remains a source numeric gap requiring schedule or companion evidence.
Drawing notation: FIXTURE LENGTH [no numeric value printed at witness]
Full label and endpoint witness independently inspected at native source resolution; no dimension number appears. This remains a source numeric gap requiring schedule or companion evidence.
Calculated from: closeout-img1297-fixture_425_427_length_unresolved
