Every dimension belongs to an object and a drawing. Original room numbers, object marks, printed values and source regions stay together—even when the answer is unresolved.
464 of 464 photographs have extraction records, containing 27,517 properties. Initial image review is not exhaustive extraction: 0 photographs have passed the full-region check. 66 numbered sheets are reconciled. Modeling and architectural registration are separate work; these counts do not establish a complete building.
Download the structured register (JSON)Original sheet identity has not yet been reconciled.
Extraction: Reviewed · extraction partial. Partial timed visual review: Partial sequential 1000px JPEG65 locator review of public/archive/drawings/complete-upright/IMG_1168.webp after OCR/catalogue and existing reports. Clockwise reading rotation 0 degrees; normalized access-image regions before rotation. No claim of full-region extraction. Partial timed visual review: Partial bounded source review. Existing measurements and identities retained; original/revision and installed applicability unresolved. Partial timed visual review: Bounded text-first follow-up using sequential upright 2200px WebP derivative inspection; this photograph is a cropped or perspective view. New local properties only; no complete-sheet or geometry acceptance claim. Partial timed visual review: undefined Partial timed visual review: undefined Partial timed visual review: Sixth-floor district-court source evidence only. Exact Court602/612 and lobby installed-instance allocation, original/revision authority and full geometry remain unresolved. Crop sourcePixelDimensions describe inspected encoded assets; normalized regions refer to corresponding whole reading-upright source frame.
Loading the selected drawing…
Scroll or pinch to inspect this drawing. Archival drawing photograph · Oregon Historical Society research collections.
Open source image separately ↗Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: DISTRICT COURTROOM DETAILS
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: 3/4" = 1'-0"
Partial drawing/detail evidence only; no installation count or complete room geometry established.
3 designs
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: 3 DESIGNS REPEATED
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: Entrance doors from foyer; clerk/judge desk elevations/plans/sections; balustrade; return grilles; clock and ceiling detail
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: Existing courtroom-602-w238-detail-extraction.md uses cleaner IMG_1169; this locator confirms sheet and detail set
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Numeric value unresolved
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Drawing notation: Local numeric properties not transferred from cleaner IMG_1169; fine witnesses still require review here
Partial drawing/detail evidence only; no installation count or complete room geometry established.
Local upper-left cornice/ceiling section attachment note; bolt size and spacing unread.
Drawing notation: BOLT TO STEEL
Local upper-left cornice/ceiling section attachment note; bolt size and spacing unread.
Numeric value unresolved
Upper-left section; no numeric value authorized.
Drawing notation: [steel and cornice dimension chains unresolved]
Upper-left section; no numeric value authorized.
30 in
Horizontal outer-frame witness of the narrow upper wall grille above the panelled door in the left elevation. Distinct from W238 lower RETURN GRILLES57.5in width; no grille count or room coordinate.
Drawing notation: 2′-6″
Horizontal outer-frame witness of the narrow upper wall grille above the panelled door in the left elevation. Distinct from W238 lower RETURN GRILLES57.5in width; no grille count or room coordinate.
55 in
Vertical outer-frame witness of the same upper grille; not wall-panel clear height or the46.25in RETURN GRILLES height.
Drawing notation: 4′-7″
Vertical outer-frame witness of the same upper grille; not wall-panel clear height or the46.25in RETURN GRILLES height.
Leader targets the narrow upper grille. Does not transfer the removable/one-inch specification from the different return-grille detail.
Drawing notation: PIERCED-CAST BRONZE GRILLE
Leader targets the narrow upper grille. Does not transfer the removable/one-inch specification from the different return-grille detail.
24 in
Legible local note beside BOLT TO STEEL at ceiling edge. The exact member/witness ownership remains unresolved; this is not an installed beam grid pitch. Review correction review-correction-20261013s-district1013i-1168-support-interval-candidate: Native original pixels show2′-4″ o.c.; earlier24in candidate is an incorrect numeric transcription. Do not use this proposal to resolve leader/member ownership or physical geometry.
Drawing notation: 2′-0″ o.c.
Legible local note beside BOLT TO STEEL at ceiling edge. The exact member/witness ownership remains unresolved; this is not an installed beam grid pitch.
Upper ceiling build-up support note; alternative member family only, with no section gauge, spacing allocation or connection size.
Drawing notation: STUDS OR CHANNELS
Upper ceiling build-up support note; alternative member family only, with no section gauge, spacing allocation or connection size.
Local ceiling build-up finish leader, independent of wood bracket material and acoustic backing; colors and samples unresolved.
Drawing notation: CEILING — POLYCHROMED
Local ceiling build-up finish leader, independent of wood bracket material and acoustic backing; colors and samples unresolved.
185 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 15′-5″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
5 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 5″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
10 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 10″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
90 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 7′-6″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
22.5 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 1′-10½″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
95 in
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Drawing notation: 7′-11″
Original left wall/door section or elevation witness in IMG1168 only. Does not close complete steel/cornice-size question or transfer a dimension from IMG1169. Exact profile endpoints, construction and historical applicability remain open.
Original white caption. Upper ceiling recess caption; ornamental plaster zone remains separate.
Drawing notation: ACOUSTICAL MATERIAL
Original white caption. Upper ceiling recess caption; ornamental plaster zone remains separate.
Original white caption. Curved leaders to large upper wall panel field and surround; exact layer/extent open.
Drawing notation: ACOUSTICAL MATERIAL
Original white caption. Curved leaders to large upper wall panel field and surround; exact layer/extent open.
Original white caption. Leader to radiator enclosure inside recess; no paint recipe or color calibration.
Drawing notation: INTERIOR PAINTED BLACK
Original white caption. Leader to radiator enclosure inside recess; no paint recipe or color calibration.
Original white caption. Leader to depicted step beside radiator base, separate from judge platform and general flooring.
Drawing notation: RUBBER TILE TREADS / WOOD NOSINGS
Original white caption. Leader to depicted step beside radiator base, separate from judge platform and general flooring.
Original white caption. Leader to depicted left fluted wall pilaster; no depth or installed count.
Drawing notation: FLUTED WOOD PILASTERS
Original white caption. Leader to depicted left fluted wall pilaster; no depth or installed count.
Original white caption. Leader to upper capital assembly in this exposure. Carving depth and companion model full geometry unresolved.
Drawing notation: CARVED CAPITALS
Original white caption. Leader to upper capital assembly in this exposure. Carving depth and companion model full geometry unresolved.
Original white caption. Left wall section leader to sash; complete frame profile/glazing/hardware open.
Drawing notation: METAL SASH
Original white caption. Left wall section leader to sash; complete frame profile/glazing/hardware open.
28 in
Same-image native note reread beneath BOLT TO STEEL resolves numeric token as2ft4, separately from prior2ft0 candidate. Leader/member ownership, exact channel/stud section and installed repetition remain open.
Drawing notation: 2′-4″ o.c.
Same-image native note reread beneath BOLT TO STEEL resolves numeric token as2ft4, separately from prior2ft0 candidate. Leader/member ownership, exact channel/stud section and installed repetition remain open.
Conflicting readings: district1013i-1168-support-interval-candidate
4 in
Vertical note at left wall section beside cornice pocket. Four inches is a source-designated nominal channel size, not full channel geometry, ceiling member depth or material thickness.
Drawing notation: 4″ CHANNEL
Vertical note at left wall section beside cornice pocket. Four inches is a source-designated nominal channel size, not full channel geometry, ceiling member depth or material thickness.
