← Back to the building1933 reconstruction · research preview

The measured building.

Every dimension belongs to an object and a drawing. Original room numbers, object marks, printed values and source regions stay together—even when the answer is unresolved.

Source photographs
464
Identified objects
4872
Verified printed values
12046
Disputed values
20

464 of 464 photographs have extraction records, containing 27,517 properties. Initial image review is not exhaustive extraction: 0 photographs have passed the full-region check. 66 numbered sheets are reconciled. Modeling and architectural registration are separate work; these counts do not establish a complete building.

Download the structured register (JSON)

Open the coordinated research model →

Clear filters
IMG_0965 · Folder 194

Room 518

Original sheet identity has not yet been reconciled.

Extraction: Reviewed · extraction partial. Partial timed visual review: Additive remaining-region review 2026-10-11; prior packages, queue and OCR read before sequential derivative inspection. Regions in native derivative coordinates. Ten inspections including one notes crop across this batch. Partial extraction only; no model changes. Partial timed visual review: Source-local printed construction property; no room geometry, installed quantity or accepted model inference. Partial timed visual review: Reuse canonical text/properties only; no new visual coverage claimed. Partial timed visual review: Bounded first pass of public/archive/drawings/complete-upright/IMG_0965.webp. Catalogue/OCR consulted first; prior reference search found only review queue. Actual derivative orientation visually verified. Raw access-image coordinates precede clockwise presentation rotation. Review partial; no modeling.

Unresolved extraction work
  • All dimension chains
  • Bronze revision exact endpoints
  • All library application mapping
  • Whole-image regional completeness not established.
  • Full dimension chains and witness endpoint reconciliation
  • Companion registration and installed instance assignment
  • Colored revision authority and remaining regional review
  • Modeling and whole-building acceptance checks outstanding
  • A–M profiles, lower track removable-piece joint endpoints, bronze revision and all-library application mapping remain open.
  • All other regions, dimensions, endpoint assignments, notes, schedules, callouts and companion details still require systematic review.
  • Source-to-room/object placement, original/revision authority and physical installation remain unresolved; modeling and whole-building checks outstanding.
  • Remaining dimensions, notes, schedules, callouts and companion details unreviewed; image not complete.
  • Dimensions and individual panels
  • Removal-joint locations
  • Hardware and sliding-door detail
  • Complete material schedule
  • All other library references

Download OCR observations (unverified)

Loading the selected drawing…

Scroll or pinch to inspect this drawing. Archival drawing photograph · Oregon Historical Society research collections.

Open source image separately ↗

12 matching properties

Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.

parallel03-img_0965-caseworkverified · observed

bronze-track-revision

DETAIL OF BRONZE / CHANGE THIS IN ALL LIBRARIES

Yellow instruction adjacent lower track K; revision applies beyond Room518 but library instance list unresolved.

IMG_0965 · Locate on drawing ↗

Drawing notation: DETAIL OF BRONZE / CHANGE THIS IN ALL LIBRARIES

Yellow instruction adjacent lower track K; revision applies beyond Room518 but library instance list unresolved.

parallel03-img_0965-caseworkverified · printed

field-check

Check on Job

Source-local component property; no whole-room geometry inference.

IMG_0965 · Locate on drawing ↗

Drawing notation: Check on Job

Source-local component property; no whole-room geometry inference.

parallel03-img_0965-caseworkverified · printed

shelf-continuity

Shelf same in upper Section

Source-local component property; no whole-room geometry inference.

IMG_0965 · Locate on drawing ↗

Drawing notation: Shelf same in upper Section

Source-local component property; no whole-room geometry inference.

parallel03-img_0965-caseworkverified · printed

shelf-material

All Mahogany

Source-local component property; no whole-room geometry inference.

IMG_0965 · Locate on drawing ↗

Drawing notation: All Mahogany

Source-local component property; no whole-room geometry inference.

detail-20261012d-img0965-section-lverified · printed

section-member-width

3″

3 in

Source-local printed construction property; no room geometry, installed quantity or accepted model inference.

IMG_0965 · Locate on drawing ↗

Drawing notation: 3″

Source-local printed construction property; no room geometry, installed quantity or accepted model inference.

detail-20261012d-img0965-section-mverified · printed

section-member-width

3″

3 in

Source-local printed construction property; no room geometry, installed quantity or accepted model inference.

IMG_0965 · Locate on drawing ↗

Drawing notation: 3″

Source-local printed construction property; no room geometry, installed quantity or accepted model inference.

parallel03-img_0965-caseworkverified · printed

room-number

ROOM 518

518 identifier

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: ROOM 518

First-pass property only; remaining detail and endpoint/component associations require review.

parallel03-img_0965-caseworkverified · printed

room-use

LIBRARY OF U.S. DISTRICT ATTORNEY

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: LIBRARY OF U.S. DISTRICT ATTORNEY

First-pass property only; remaining detail and endpoint/component associations require review.

parallel03-img_0965-caseworkverified · printed

lower-track-pieces

LOWER TRACKS TO BE IN TWO PIECES WITH JOINTS HERE.

2 pieces

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: LOWER TRACKS TO BE IN TWO PIECES WITH JOINTS HERE.

First-pass property only; remaining detail and endpoint/component associations require review.

parallel03-img_0965-caseworkverified · printed

track-removal-reason

IT BEING NECESSARY TO REMOVE SECTIONS IN ORDER TO REMOVE A DOOR WHEN NECESSARY

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: IT BEING NECESSARY TO REMOVE SECTIONS IN ORDER TO REMOVE A DOOR WHEN NECESSARY

First-pass property only; remaining detail and endpoint/component associations require review.

parallel03-img_0965-caseworkverified · printed

library-reference

Check other libraries also 6″ is above finished fl.

6 in

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: Check other libraries also 6″ is above finished fl.

First-pass property only; remaining detail and endpoint/component associations require review.

parallel03-img_0965-caseworkverified · printed

section-mark

A

First-pass property only; remaining detail and endpoint/component associations require review.

IMG_0965 · Locate on drawing ↗

Drawing notation: A

First-pass property only; remaining detail and endpoint/component associations require review.
