Every dimension belongs to an object and a drawing. Original room numbers, object marks, printed values and source regions stay together—even when the answer is unresolved.
464 of 464 photographs have extraction records, containing 27,517 properties. Initial image review is not exhaustive extraction: 0 photographs have passed the full-region check. 66 numbered sheets are reconciled. Modeling and architectural registration are separate work; these counts do not establish a complete building.
Download the structured register (JSON)Original sheet identity has not yet been reconciled.
Extraction: Reviewed · extraction partial. Partial timed visual review: Queue, OCR and prior doors-03/counter-03 packages searched before ten sequential single-image inspections. Additive selected remaining-region review of complete-upright derivative. Existing verified evidence reused, not duplicated. No modeling or full coverage claim. Prior level-7 floor assignment not independently established by title. Partial timed visual review: Selected large left profile and central right vertical chain. Prior 7 inch by 4 foot 6 inch annotation and conflicting overall height readings reused without duplication. No Court of Appeals floor inference. Partial timed visual review: Bounded additive regional inventory; historical room/type marks remain separate from stable dataset object IDs. Partial timed visual review: Partial first-pass review; catalogue, OCR and existing research search preceded sequential visual inspection. Access derivative is visibly upside down despite complete-upright path; rotationDegrees 0 preserves native access pixels. Selected clear dimension note only. No modeling; all images remain incomplete. Partial timed visual review: Assigned source disposition and selected source-local witnesses only; historical missing work retained. Reuse rectangles are documentary crosswalks, not exhaustive inspected coverage.
Loading the selected drawing…
Scroll or pinch to inspect this drawing. Archival drawing photograph · Oregon Historical Society research collections.
Open source image separately ↗Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
Native access derivative is upside down (180 degrees from reading upright); rotationDegrees 0 preserves untransformed native coordinates.
Native access derivative is upside down (180 degrees from reading upright); rotationDegrees 0 preserves untransformed native coordinates.
Native upper-left elevation/title matches IMG_0957; coordinate registration not calibrated.
Native upper-left elevation/title matches IMG_0957; coordinate registration not calibrated.
Numeric value unresolved
Requires rotated high-resolution crop; no fractional reading inferred from full sheet.
Requires rotated high-resolution crop; no fractional reading inferred from full sheet.
6 in
Span between the dimension witnesses across upper profile in the large lower-left detail when reading upright; not overall opening width.
Drawing notation: 6″
Span between the dimension witnesses across upper profile in the large lower-left detail when reading upright; not overall opening width.
6 in
Separate lower horizontal dimension across left trim profile in upright view.
Drawing notation: 6″
Separate lower horizontal dimension across left trim profile in upright view.
5 in
Dimension immediately to right of lower 6 inch trim span in upright view. End witnesses retained; exact named component not assigned.
Drawing notation: 5″
Dimension immediately to right of lower 6 inch trim span in upright view. End witnesses retained; exact named component not assigned.
4 in
Large upright vertical chain from underside of head moulding to lower edge of first plain recess; no overall assembly height inferred.
Drawing notation: 4″
Large upright vertical chain from underside of head moulding to lower edge of first plain recess; no overall assembly height inferred.
3 in
Next segment below 4 inch segment in upright vertical chain.
Drawing notation: 3″
Next segment below 4 inch segment in upright vertical chain.
6.375 in
Central recessed segment of large section, bounded by adjoining moulded lips. Distinct evidence from small elevation panel detail.
Drawing notation: 6⅜″
Central recessed segment of large section, bounded by adjoining moulded lips. Distinct evidence from small elevation panel detail.
Numeric value unresolved
Adjacent lip fractions and summed equality visible but withheld pending higher-resolution source and witness review.
Adjacent lip fractions and summed equality visible but withheld pending higher-resolution source and witness review.
Small inverted note visible; exact wording/applicability require crop. Do not substitute companion panel removability for jamb removability.
Small inverted note visible; exact wording/applicability require crop. Do not substitute companion panel removability for jamb removability.
Numeric value unresolved
Colored changes remain separate from white fractions; no arithmetic reconstruction from locator.
Colored changes remain separate from white fractions; no arithmetic reconstruction from locator.
Conflicting readings: detail-20261011p-956-003 detail-20261012d-956-007
Selected visible note only; does not establish complete assembly geometry.
Drawing notation: WINDOW TRIM & JAMBS COURT OF APPEALS
Selected visible note only; does not establish complete assembly geometry.
7 in
Yellow 7″ x 4′6″ long note at native center-left, exact member applicability unresolved.
Drawing notation: 7″
Yellow 7″ x 4′6″ long note at native center-left, exact member applicability unresolved.
54 in
Same yellow note; do not infer location or quantity.
Drawing notation: 4′-6″ LONG
Same yellow note; do not infer location or quantity.
Note beside right jamb of small elevation when reading upright; applies to jamb, not neighboring removable panel. Actual access-equivalent frame locus differs from legacy prior rectangle; closure held for primary frame/witness review.
Drawing notation: Removable Jamb
Note beside right jamb of small elevation when reading upright; applies to jamb, not neighboring removable panel. Actual access-equivalent frame locus differs from legacy prior rectangle; closure held for primary frame/witness review.
White leader labels catch at join below upper profiled member of large section. Hardware type designation only; installation count, fasteners and recess dimensions unresolved.
Drawing notation: Sunk Catch
White leader labels catch at join below upper profiled member of large section. Hardware type designation only; installation count, fasteners and recess dimensions unresolved.
6.5 unit-unresolved
Yellow circled numeric glyph above large-section upper width witness. No independent unit mark verified at this glyph; neighboring 7-inch by 4-foot-6-inch note does not supply unit authority or target equality.
Drawing notation: 6½
Yellow circled numeric glyph above large-section upper width witness. No independent unit mark verified at this glyph; neighboring 7-inch by 4-foot-6-inch note does not supply unit authority or target equality.
1.625 unit-unresolved
White vertical fraction between first plain recess and central moulded/glazed portion in inspected large-section crop. Unit mark not independently verified; does not inherit inches from prior neighboring chain.
Drawing notation: 1⅝
White vertical fraction between first plain recess and central moulded/glazed portion in inspected large-section crop. Unit mark not independently verified; does not inherit inches from prior neighboring chain.
1.625 unit-unresolved
Separate lower white vertical fraction below central 6⅜ glyph, not an arithmetic equality or total chain. No unit mark independently verified.
Drawing notation: 1⅝
Separate lower white vertical fraction below central 6⅜ glyph, not an arithmetic equality or total chain. No unit mark independently verified.
Selected white finish clause beneath small Court of Appeals window-trim elevation; applies to this source assembly note, not IMG_0955 varnish finish. No governing revision selected.
Drawing notation: Stain to approved color for 2 coats of Orange shellac and rubbed wax finish
Selected white finish clause beneath small Court of Appeals window-trim elevation; applies to this source assembly note, not IMG_0955 varnish finish. No governing revision selected.
2 count
Count within orange-shellac finish instruction; not installed quantity.
Drawing notation: 2 coats
Count within orange-shellac finish instruction; not installed quantity.
Selected white sequence instruction only; exact panel instances and assembly registration remain unresolved.
Drawing notation: Stain panels before assembling
Selected white sequence instruction only; exact panel instances and assembly registration remain unresolved.
Selected white back-primer sentence beneath panel sequence. Last succeeding jamb/trim line remains uncertain; this sentence cannot close that neighboring clause.
Drawing notation: Backs primed lead and oil
Selected white back-primer sentence beneath panel sequence. Last succeeding jamb/trim line remains uncertain; this sentence cannot close that neighboring clause.
First material line clips at upper crop edge and lettering is faint. Do not infer oak/cherry specification, species, or relationship to companion fir/mahogany notes.
Drawing notation: All American ... red Cherry [intervening lettering unresolved]
First material line clips at upper crop edge and lettering is faint. Do not infer oak/cherry specification, species, or relationship to companion fir/mahogany notes.
43 drawing-number
Source title block DRAW. NO field only; does not establish sheet relationship to governing plans.
Drawing notation: 43
Source title block DRAW. NO field only; does not establish sheet relationship to governing plans.
