Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
parallel-img_0953-assemblyverified · printed
section-a-a-right-panel-vertical-span
2′-0⅞″24.875 in
Vertical dimension inside rightmost raised-panel field of Section A-A. Source-local inner panel span only; excludes surrounding rails/mouldings and does not supply total counter height.
IMG_0953 · Locate on drawing ↗Drawing notation: 2′-0⅞″
Vertical dimension inside rightmost raised-panel field of Section A-A. Source-local inner panel span only; excludes surrounding rails/mouldings and does not supply total counter height.
parallel-img_0953-assemblyverified · printed
upper plan horizontal span
12′-8″152 in
Printed span between witness lines; left geometry cropped, not claimed as final total counter length.
IMG_0953 · Locate on drawing ↗Drawing notation: 12′-8″
Printed span between witness lines; left geometry cropped, not claimed as final total counter length.
parallel-img_0953-assemblyverified · printed
lower right return span
3′-5⅞″41.875 in
Selected source span or note only; not room geometry or full assembly dimensions.
parallel-img_0953-assemblyverified · printed
lower right internal span
2′-6″30 in
Selected source span or note only; not room geometry or full assembly dimensions.
parallel-img_0953-assemblyverified · printed
upper prior return span
3′-5⅞″41.875 in
Circled original notation retained separately from colored corrections; not assumed final.
parallel-img_0953-assemblyverified · printed
upper right internal span
2′-6½″30.5 in
Differs from lower 2′-6″; retain separately pending witness-line reconciliation.
parallel-img_0953-assemblyunreviewed · observed
colored return revision unresolved
UnresolvedNumeric value unresolved
Orange fractions need high-resolution crop.
parallel-img_0953-assemblyunreviewed · observed
exposed mahogany species candidate
Hard close grain Bataan or Tangile MahoganyCandidate only; previous uncertain species record remains unresolved.
IMG_0953 · Locate on drawing ↗Drawing notation: Hard close grain Bataan or Tangile Mahogany
Candidate only; previous uncertain species record remains unresolved.
parallel-img_0953-assemblyverified · printed
preassembly finish coat count
2 coats2 count
Panel finish instruction; prior package preserves complete text.
parallel-img_0953-assemblyverified · printed
printed room designation
ROOM 315Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · observed
counter top original material
Counter top Plain White OakOriginal white-oak text visibly crossed out; do not treat as final specification.
IMG_0953 · Locate on drawing ↗Drawing notation: Counter top Plain White Oak
Original white-oak text visibly crossed out; do not treat as final specification.
parallel-img_0953-assemblyverified · observed
counter top revised material
MAHOGANYSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyunreviewed · observed
exposed material options
Hard close grain [species uncertain] or [species uncertain] MahoganySelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Hard close grain [species uncertain] or [species uncertain] Mahogany
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
unexposed material
Unexposed parts Yellow PineSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
shelf material
Shelves laminated 3 ply Yellow PineSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Shelves laminated 3 ply Yellow Pine
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
shelf lamination layer count
3 ply3 count
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
shelf thickness notation
7/16″0.4375 in
Terminal shelf-note fraction; review intended total/per-layer meaning before modeling.
parallel-img_0953-assemblyverified · printed
adjustable shelf cleat slot spacing
1¼″ O.C.1.25 in
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
counter top core material
W.P. Chestnut or poplarSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
counter top core strip maximum width
not over 1″ wide1 in
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
panel core construction
Panel cores laminatedSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
veneer selection
Veneers selected for ornamental grainSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Veneers selected for ornamental grain
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
drawer joinery
Drawers dovetailed to fronts and grooved for bottoms and backsSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Drawers dovetailed to fronts and grooved for bottoms and backs
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
drawer side extent and material
Sides to run back as far as possible (Hardwood)Selected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Sides to run back as far as possible (Hardwood)
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
drawer runners and guides material
Hardwood runs and guidesSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
drawer bottom lamination layer count
3 ply Bottoms3 count
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
exposed surface preparation
Sponge exposed parts for natural finish and sand smoothSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Sponge exposed parts for natural finish and sand smooth
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
panel finish before assembly
Panels filled or stained and given 2 coats of finish before assemblySelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Panels filled or stained and given 2 coats of finish before assembly
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
exposed finish
Stain to approved sample for a shellaced and varnish finishSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Stain to approved sample for a shellaced and varnish finish
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
accessible internal finish
Inside accessible parts including drawers stained, shellacked and sandedSelected visible note only; does not establish complete assembly geometry.
IMG_0953 · Locate on drawing ↗Drawing notation: Inside accessible parts including drawers stained, shellacked and sanded
Selected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
back surface primer
Backs primed lead and oilSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
hardware installation requirement
Hardware installedSelected visible note only; does not establish complete assembly geometry.
parallel-img_0953-assemblyverified · printed
section A-A drawer bay horizontal span
2′-6″30 in
Span above left drawer bay at section A-A; not whole counter width.
parallel-img_0953-assemblyverified · printed
first_exposed_mahogany_option_literal
BataanFirst named option is readable as Bataan in the all-exposed-parts clause. Second option lettering remains unresolved; this token does not close either whole-clause species question.
IMG_0953 · Locate on drawing ↗Drawing notation: Bataan
First named option is readable as Bataan in the all-exposed-parts clause. Second option lettering remains unresolved; this token does not close either whole-clause species question.
parallel-img_0953-assemblyunreviewed · printed
second_exposed_mahogany_option_followup
All exposed part. Hard close grain Bataan or Tangela [last name lettering uncertain] MahoganyNative crop suggests Tangela/Tangile ambiguity. Historical Tangile and unspecified species records retained separately; no taxonomic equivalence or governing material choice inferred.
IMG_0953 · Locate on drawing ↗Drawing notation: All exposed part. Hard close grain Bataan or Tangela [last name lettering uncertain] Mahogany
Native crop suggests Tangela/Tangile ambiguity. Historical Tangile and unspecified species records retained separately; no taxonomic equivalence or governing material choice inferred.
Conflicting readings: detail-20261011p-953-007 parallel-img_0953-exposed-species
parallel-img_0953-assemblyverified · observed
colored_return_right_fraction_literal
5/16″0.3125 in
Orange circled fraction at right side of return dimension witnesses. Explicit double-prime mark visible with numerator; precise member/endpoints and other colored return changes remain unresolved. This local fraction does not close the whole colored-return question.
IMG_0953 · Locate on drawing ↗Drawing notation: 5/16″
Orange circled fraction at right side of return dimension witnesses. Explicit double-prime mark visible with numerator; precise member/endpoints and other colored return changes remain unresolved. This local fraction does not close the whole colored-return question.
