Every dimension belongs to an object and a drawing. Original room numbers, object marks, printed values and source regions stay together—even when the answer is unresolved.
464 of 464 photographs have extraction records, containing 27,517 properties. Initial image review is not exhaustive extraction: 0 photographs have passed the full-region check. 66 numbered sheets are reconciled. Modeling and architectural registration are separate work; these counts do not establish a complete building.
Download the structured register (JSON)Original sheet identity has not yet been reconciled.
Extraction: Reviewed · extraction partial. Partial timed visual review: Partial first-pass review of public/archive/drawings/complete-upright/IMG_0942.webp. Derivative is upside down despite directory name. Large partition plan and sections surveyed; fine values deferred. Source regions use access-image coordinates. No floor inference or modeling. Partial timed visual review: Additive partial remaining-region review of complete-upright access derivative. Prior verified readings remain in their packages. No floor inference, geometry approval or full extraction claim. Partial timed visual review: Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred. Partial timed visual review: undefined
Loading the selected drawing…
Scroll or pinch to inspect this drawing. Archival drawing photograph · Oregon Historical Society research collections.
Open source image separately ↗Printed values, calculations, image traces and observed counts are different kinds of evidence. “Verified” applies to the specific reading—not to the whole room or model.
Selected source evidence; partial review.
Drawing notation: Bays C, D, E, F, G, H, I, J
Selected source evidence; partial review.
Selected source evidence; partial review.
Drawing notation: Phil. Mahogany
Selected source evidence; partial review.
Selected source evidence; partial review.
Drawing notation: Note - check job for ... [mullion/jamb/sill/head wording incomplete]
Selected source evidence; partial review.
Selected source evidence; partial review.
Drawing notation: Trim for transoms over door
Selected source evidence; partial review.
Numeric value unresolved
Numerous printed chains visible; no numerical geometry asserted at current reading scale.
Numerous printed chains visible; no numerical geometry asserted at current reading scale.
180 degrees
Access derivative is upside down. Additive correction to prior 0-degree image record; coordinates retained in unrotated access-image space.
Access derivative is upside down. Additive correction to prior 0-degree image record; coordinates retained in unrotated access-image space.
8 in
Direct source notation, applies only to depicted detail; no building geometry inference.
Drawing notation: 8" Mullion Csg
Direct source notation, applies only to depicted detail; no building geometry inference.
4.5 in
Direct source notation, applies only to depicted detail; no building geometry inference.
Drawing notation: 4½ casing at jambs
Direct source notation, applies only to depicted detail; no building geometry inference.
Registration wording remains partial; no assumed dimensions.
Drawing notation: Note — check job for muntin, jamb, sill and head ... [remainder unresolved]
Registration wording remains partial; no assumed dimensions.
Direct source notation, applies only to depicted detail; no building geometry inference.
Drawing notation: SEE PREVIOUS NOTE
Direct source notation, applies only to depicted detail; no building geometry inference.
Revised reading of earlier incomplete job-check note; check-on-job dependency is explicit. Earlier muntin transcription preserved separately.
Drawing notation: Note - Check Job for Mullion, Jamb, Sill and Head / Trim for Transoms over Door
Revised reading of earlier incomplete job-check note; check-on-job dependency is explicit. Earlier muntin transcription preserved separately.
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
Drawing notation: Exposed parts stained and shellacked
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
Drawing notation: Concealed parts primed lead and oil
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
14 in
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
Drawing notation: 1'-2"
Source-local partial detail evidence only; no installed building geometry, quantity or host placement inferred.
